1-156-275 - Oxford Science Archive/Heritage Images

Distillation, 1882. Cross-section showing a furnace heating a still. Matter distilled is discharged through the beak of the alembic and is condensed in the worm that runs through the refrigerator (cold water bath) before being collected at the bottom. From Physics in Pictures by Theodore Eckhardt. (London, 1882).
