Gauge, Ammeter, Main Bus, 1960s. Creators: Weston Instruments, Anne Weston.

Gauge, Ammeter, Main Bus, 1960s. Creators: Weston Instruments, Anne Weston.

2-839-803 - Heritage Art/Heritage Images

This main bus ammeter measured the current from the batteries like those used in Gemini 3, IV, and VI. Located on the Gemini pilot's panel, the No. 1 scale displayed main batteries 1 and 2 and the No. 2 scale displayed main batteries 3 and 4. Fuel cells replaced batteries on Gemini V and VII through XII. This ammeter did not fly in space. Weston Instruments made the artifact and NASA transferred it to NASM in 1972.

Image Details

People Information

Creator
  1. Weston Instruments, attributed to: : Maker, manufacturer
  2. Anne Weston, attributed to: American: Maker, manufacturer
Medium
  1. Adhesive
  2. Adhesive tape
  3. Cadmium plating
  4. Copper alloy
  5. Glass
  6. Non-magnetic white metal alloy
  7. Paint
  8. Steel
Picture Type
  1. Instruments-miscellaneous
  2. Object
Category Hierarchy

Science & Nature Technology & Innovation

Science & Nature Discovery & Exploration
