Indicator, Autosyn, Fuel Pressure, C-14A. Creator: Bendix Aviation.

Indicator, Autosyn, Fuel Pressure, C-14A. Creator: Bendix Aviation.

2-839-812 - Heritage Art/Heritage Images

3-1/8 in.dia; 0 to 25 lb;autosyn indicator;ww 2;electrical,26v. The Autosyn was a system developed by the Eclipse-Pioneer Division of the Bendix Aviation Corporation to eliminate the cumbersome plumbing required for instrumentation in increasingly large aircraft. Instead of having many feet of piping, vulnerable to blockage or leaks, the autosyn system used a transmitter located at the source of the input that converted the mechanical or electro-mechanical impulses from a sensor into electrical signals that were sent to a standardized indicator on the instrument panel. The indicator would have a simple easily mounted face that was appropriate to the input sensed by the transmitter.


Image Details


People Information

Creator
  1. Bendix Aviation, attributed to: American: Manufacturer

Medium
  1. Adhesive
  2. Adhesive tape
  3. Copper alloy
  4. Glass
  5. Ink
  6. Non-magnetic white metal alloy
  7. Paint
  8. Steel
  9. Wax

Picture Type
  1. Instruments-engine & fuel
  2. Object

Category Hierarchy

Science & Nature Technology & Innovation


Digital Image Size

Pixel Dimensions (W x H) : 3648x3648
File Size : 38,988kb


Aliases

  1. A19601189000
  1. NASM-B3CFA8526C962_001-000001.txt
  1. 0990010396
  1. 2-839-812
  1. 2839812
  1. A19601189000
