Antenna Loop, Dual, from P-51 "Excalibur III", 1950s. Creator: Unknown.

Antenna Loop, Dual, from P-51 "Excalibur III", 1950s. Creator: Unknown.

2-840-015 - Heritage Art/Heritage Images

Dual antenna loops mounted side by side on ovoid stainless steel plate. Loops are energized with small electric motors mounted adjacent to the base of each loop. Large fiber gears at the base of each loop driven by small metal gear. Dual loops, independent rotation allows fixes to be taken on two stations simultaneously.

Image Details

People Information

Creator
  1. Unknown, attributed to: :
Medium
  1. Aluminum
  2. Copper alloy
  3. Ink
  4. Micarta
  5. Paint
  6. Phenolic resin
  7. Plastic
  8. Stainless steel
  9. Steel
  10. Synthetic rubber
Picture Type
  1. Avionics-electronic/satellite navigation
  2. Object
Category Hierarchy

Science & Nature Technology & Innovation

Trade & Industry Communications

Digital Image Size

Pixel Dimensions (W x H) : 5616x3744
File Size : 61,601kb

Aliases

  1. A19520088000
  1. NASM-NASM2013-01500.txt
  1. 0990010599
  1. 2-840-015
  1. 2840015
  1. A19520088000
